What we do
Sheet Metal Stamping and Blanking, Assembly, Bending and Wire Welding.
We have presses from 30 to 800 tons.
Our company has been in the sheet metal stamping business for more than 40 years, processing high strength and deep stamping materials in the automotive, household appliance, construction, fixture parts and shelving sectors.
200 ton press
Swan neck machine, machine table 1300 x 800 stroke 35 /200, with feeder
ALIX electronic with opening rollers for pilot needles
Press 500 tons PRESSIX
ALIX electronic feeder with opening head for dies with pilot needles,
belt capacity 900 x 3.5 mm. max processed thickness 12 x 150, reel capacity 60 q.li.
- Bench size 2700 X 1350 mm.
- Stroke 250
- 120 mm mace adjustment.
- Adjustable number of cycles 18-47 minute
- Lateral passage between shoulders 950 mm.
- Max light p.m.i. high adjustment 650 mm.
500-ton press. Manzoni (Double reduction)
ALIX electronic feeder with opening head for dies with pilot needles, for
belts measure 600 x 4 reel 70 q.li
- Bench size 3100 x 1500
- Stroke 500
- Mace adjustment 250 mm
- Adjustable number of cycles 12 - 35 minute
- Lateral passage between shoulders 1250 mm.
- Maximum light p.m.i. 815 mm.
- Maximum light p.m.s 1315 mm.
- No. 3 cushion sheet metal presses with a thrust of 120 ton. Stroke 250
800-ton press. Invernizzi GNLM2 3600-1500-400
ALIX electronic feeder with opening head for dies with pilot needles, capacity
belts size 1200 x 3, reel capacity 100 q.li.
- Mobile bench size 3600 x 1500
- Mace stroke 400 mm. with LINK LEVER system, 60% stroke slowdown at 120 mm. from p.m.i.
- Working thickness mm. 12.6
- Adjustable number of cycles 4-40 minutes
- Sledgehammer adjustment 300 mm.
- Light max p.m.i. 900, with high adjustment
- Lateral passage between uprights 1450 mm. with transfer arrangement
400-ton press. Invernizzi GNLM2 3000-1400-350
ALIX electronic feeder with opening head for dies with pilot needles, capacity
belts size 1000 x 3 – 800 x 4, reel capacity 70 q.li., max. coil diameter 1800
mm.
- Bench size 3000x1400
- Mace stroke 350 mm. with LINK LEVER system, 60% stroke slowdown at 120 mm. from p.m.i.
- Working thickness mm. 12.5
- Adjustable number of cycles 11-50 minute
- Sledgehammer adjustment 300 mm.
- Light max p.m.i. 850, with high adjustment
- Lateral passage between posts 1080 mm. with transfer arrangement
Bending Press GADE PS-C 3160
- Working Area 3000mm
- Power 200 ton
- Angle control
Forklifts and Overhead Cranes
- STILL 30 q.li / 45 q.li and 50 q.li forklift truck
- OMIS bi-beam overhead crane capacity 15 ton.
Blanking and stamping with manual dies:
70 ton press
100 ton press
Press 65 tons
30 ton press
Quality materials, constantly updated machinery and passion for generations
Contact us for your project
We guarantee professionalism and maximum availability and flexibility in all our achievements.
